Description
Versatility: The 2Banger can be mounted alone, or linked together into a serious light bar. Each set of pods includes universal pedestal mounts for an easy install on any flat surface, like your steel bumper or the the wide-variety of application-specific A-Pillar brackets we offer. The BangerBar links offer a turn-key way to bolt your Bangers together into a bespoke light bar, where you spec the color of the light. You spec the beam optics. You set the radius. And then you destroy the darkness. For more details, look for product listings dedicated to the BangerBars.
NCS Flood Beam: Provides plenty of ambient light with coverage in every direction, making them the perfect solution for low-speed driving, rock crawling, back-up lights, or even illuminating your campgrounds. Flood optics do not project far into the distance, but are the undoubtedly the weapon of choice for comfortably illuminating everything in your local space.
All Weather: The white-output version is ideal for all-around visibility. For those who desire optimal output in rain, snow, or fog–the Yellow-output version will slay in shady weather. Morimoto has opted for Phosphor-converted Yellow LEDs that produce yellow light at the origin, which is the most effective way to penetrate through particles in the air without compromising output (Filtering white light through a yellow lens achieves the look, but no actual performance benefit in poor weather)
Reliability: With power comes great responsibility. Extensive effort went into ensuring the reliability of the product. High power means high heat, which is why the 2Banger features a copper DTP (direct thermal path) PCB that maximizes heat-transfer to the radiator, which has been optimized through numerous rounds of thermal analysis. The cast aluminum shell is electroplated before powder coating to withstand flaking. The gasket system, integrated DT power connection, and breather valves all designed according to IP69K standards for full weather resistance. Street Legality: When aimed properly, the Spot and Combo beam patterns will comply with SAE J581 standards for an auxiliary high beam. If you’re looking for a high-performance street-legal LED pod to use as a fog light, the 2Banger wide beam model has been verified compliant with the latest SAE-F regulation for on road use by Calcoast Labs in California.
Power Up: The Morimoto 2Banger LED Pods have been developed from the ground up to set a new standard in their segment, and the same goes for the optional wire harness. If you want the best, bingo. Not one component on the harness was overlooked for the sake of cost or simplicity. Triple sealed proprietary 4-pin relay with hanger. Proprietary over-molded inline fuse holder with 20A mini fuse. DT06-2S female outputs with dual seals. Stainless steel power and ground terminals. Proprietary M-Spec push button switch with Yellow-LED backlight.
- Universal: With Included U Brackets
Quick Specs
Tech Specs:
- Intensity: 260 Cd (Post Warm-Up) (2.6 lux @ 10m)
- Input: Integrated Deutsch DT 2-Pin
- Input Voltage: 9-18V DC
- Power (Stabilized): 13.5w
- Current: 1.5A @ 13.5V DC
- Peak Luminosity (lm)(raw): 900lm
- Dimensions: 81.0mm W, 49.8mm H (63.5mm w/ Bracket), 59.2mm D
- Light Source: 2x Nichia NCSY131F (3000K)
- Material: Makrolon LED PC (Lens), Powdercoated Die Cast Aluminum (Housing)
- IP RATING: IP69K (Dust / High Pressure Water Resistant)
Other Specs:
- Country of Origin: CN
- Dims (in) 10.0 x 4.25 x 3.0
- Weight (lbs): 2.0
- DOT Compliant: Yes
- Prop 65: Yes
What’s Included
- LED Pods: 2x (One Pair) Morimoto 2Banger NCS Flood (Yellow)
- Brackets: 2x (One Pair) Universal Bottom Mount U Brackets
- Hardware: Complete pack (stainless steel)
Instructions
Instructions (pdf)
Fitment
: N/A
